Hoshizaki FTE-120SD-GN SS2FZ 265L

FTE-120SD-GN SS2FZ

  • Complete with stainless steel top.
  • Standard with 4 shelves / 2 doors.
  • Programmable electronic controller and display.
  • 2 years parts and labour warranty.
  • Comes standard with 4 x lockable (115 mm) castors (not legs).
  • Optional Adjustable legs 150 – 180mm (Sold separately).

Interior Stainless Steel, ABS Plastic
Exterior Stainless steel, Galvanized Steel (Rear/Bottom)
Max Storage Capacity 265L
Temperature Control Microprocessor adjustable from -25°C to -7°C
Evaporator Fin & Tube type
Outside Dimensions
Width		 1200mm
Outside Dimensions
Depth		 700mm
Outside Dimensions
Height		 815mm
(Includes 115mm Castors)
Inside Dimensions
Width		 830mm
Inside Dimensions
Depth		 527mm
Inside Dimensions
Height		 588mm
Weight Net 87kg
Packed Weight 97kg
Refrigeration System
Forced Air Circulation
AC Supply Voltage 1 Phase 220-240V 50Hz/10Amp Plug
Amperage Rated: 2.8A
Refrigerant R404A
Operating Conditions Ambient Temp.: 5-43°C
Voltage Range: Rated Voltage ±6%
 Electrical Consumption Motor 460W (Power Factor 74%), Heater 371W, Refrigeration 501W,
Defrost 365W
Additional Parts 95001013 Adjustable Leg
95002993 Adjustable Leg
79001076 Castor Grey 180mm (each)

Unpack

  1. After unpacking the water cooler, wipe with a soft cloth. Check the unit for evidence of rough handling.
  2. Place the machine on a hard, flat surface. Make certain the unit is level. The unit should not be close to sources of heat otherwise performance may be affected.

Install

  1. Follow the instructions for setting up the Tri-Stage Refillable Bottle on the product page here.
  2. Ensure proper ventilation be allowing 75 mm clearance on each side of the fountain.
  3. Place water bottle on top of unit and allow tank to fill.
  4. Hold down the taps until a steady stream of water comes from the tap.
  5. Check all connections for water leaks.
  6. Flush fresh water through unit for five minutes to ensure any residual water from testing is cleared.
  7. Plug the cooler into the building electrical supply and for the cook and cold model: Switch to the ON position. The first time the water cooler is used, you will have to wait at least 45 minutes for cold and hot water.

Data_Sheet
User_Manual
Drinking_Water_Solutions

$3,156.00

Categories: ,
Facebook
LinkedIn
WhatsApp
Email
  • Money Back Guarantee

  • Top Quality Assurance

  • Fast & Secure Checkout

Additional information

265L 2 Door Underbench Gastronorm Freezer

PACKED TO PERFORM IN ANY BUSY KITCHEN
The FTE-120SDA-GN is designed for busy kitchens who demand quick easy access to chilled and fresh foodstuff

Description

Item Number: 97000005
